A mining safety Fushun AT long-wheelbase medium-roof fuel vehicle with a reinforced body and automatic transmission, suitable for mine commuting, inspection, and operation support.
A mining safety Fushun AT long-wheelbase medium-roof fuel vehicle with a reinforced body and automatic transmission, suitable for mine commuting, inspection, and operation support.
| Length × width × height, mm | 5998×2098×2360 |
| Wheelbase | 3750 |
| Curb weight | 2.5 t |
| Front / rear track | 1745/1642 |
| Maximum load capacity | Max. load 4.2 t |
| Front / rear axle load | 1.5 t front / 2.8 t rear |
| Front / rear axle ratio | 4.556 |
| Gradeability | More than 14° |
| AT transmission | Gears: 1/2/3/4/5/6/7/8/R; ratios: 5/3.2/2.143/1.72/1.314/1/0.822/0.64/3.456 |
| Engine | NB2.5 non-road T4 |
| Displacement | 2.5 |
| Diesel engine power, kW | 130 |
| Maximum diesel engine torque, Nm | 450 |
| Front suspension | MacPherson independent suspension |
| Rear suspension | Leaf spring dependent suspension |
| Transfer case | Electronically controlled chain-wheel mechanical part-time 4WD |
| Tires | 225/75 R16 |
| Additional equipment | Full-vehicle air conditioning / hydraulic power steering |
